Ignition System
Electronic Control Unit – EFi Spark Ignition
Starting
Integrated Starter Generator & Hand Starter
Type
4 Stroke, Single Cylinder Liquid Cooled,
Si-Engine
Si-Engine
Max Speed
65 km/h
Displacement
225.8 cc
Max Power
7.8 kW @ 4750 rpm
Maximum Torque
18.5 Nm @ 3000 rpm
Transmission
4 Forward and 1 Reverse speed,Constant Mesh,
Fork & Cam Type Shift Mechanism
Fork & Cam Type Shift Mechanism
Type
Semi Monocoque
Front & Rear
Swing Arm with Hydraulic damper & Coil Spring
Front & Rear
Drum, Hydraulic
Rim size - Front & Rear
3.00 D x 8"
Tyre size - Front & Rear
4.00 – 8,76F 6 PR,
4.00 – 8,76E 6 PR
4.00 – 8,76E 6 PR
Battery
12 V, 32 Ah
Head Lamp
35/35 W, DC
Tail Lamp, Stop Lamp
21 W, 5 W
Turn Signal Lamp
10 W
Reverse Lamp
21 W
Warning Lamp
Malfunction Indication Lamp,
Battery Indication Lamp,
Low Engine Oil,
Brake Oil & Fuel Warning (Petrol)
Battery Indication Lamp,
Low Engine Oil,
Brake Oil & Fuel Warning (Petrol)
Fuel Tank Capacity
8.5 ± 0.5 litre (Petrol)
Ground Clearance
169 mm
Kerb Weight with 90% fuel
366 kg
Overall Height
1740 mm
Overall Width
1329 mm
Overall Length
2647 mm
Wheelbase
1990 mm
Wheel Track
1150 mm
Gradeability
12°
