TECH SPECS

  • Type Single Cylinder, 4 Stroke, fuel injection, air cooled spark ignition engine
  • Bore (mm) 53.5 mm
  • Stroke (mm) 48.8 mm
  • Displacement (cc) 109.7
  • Compression Ratio 10.0 : 1
  • Max Torque (Nm)@rpm 8.7 @ 4500
  • Max Power (kW)@rpm 6.1 @ 7350
  • EFI System ETFi Eco Thrust Fuel Injection Technology
  • Air Filter Paper Filter element
  • Clutch System Wet-multi plate type
  • Emission Compliance BS VI
  • Gear Shift Pattern All Up
  • Max Speed kmph 90 Kmph
  • Primary Transmission Spur Gears
  • Secondary Transmission Chain & Sprockets
  • Transmission 4 Speed Constant Mesh
  • Ignition System ECU - Electronic Control Unit
  • Battery 12V, 4 Ah
  • Headlamp (W) 12V, HS1 35/35W x 1
  • Position / DRL Lamps 12V, LED 4W
  • Tail Lamp / Stop Lamp (W) 12V, 5/21W X 1
  • Horn Type / No 12V, DC X 1
  • Front Telescopic oil damped
  • Rear 5 Step adjustable Hydraulic Shock Absorber
  • Length (mm) 1950
  • Width (mm) 705
  • Height (mm) 1080
  • Wheel Base (mm) 1236
  • Ground Clearance (mm) 175
  • Kerb Weight (kg) 110 (Kick Start Model)
  • Engine Oil (Litres) 1
  • Fuel Tank Capacity (Litres) 10
  • Front (Type/Dia) (mm) Drum / 130
  • Rear (Type/Dia) (mm) Drum / 110 (Sync)
  • Rear 3.0 x 17" 50P 6PR
  • Front 2.75 x 17" 41P 4PR
